Model: DX-40F
|
Leveling Casters
DX-40F Leveling Caster with Top Plate
Nylon Wheel 43mm · 73+8mm Height · 50kg Load
43mm
Wheel Ø
50 kg (110 lbs)
Single Load
73
Height
Top Plate (4 holes)
Mounting
Product Overview
The DX-40F is a compact leveling caster with top plate mounting, designed for light equipment and furniture. Features integrated mobility and leveling in one unit — easily move equipment on nylon wheels, then adjust the leveling pad to stabilize in place. One-piece formed shell provides durability and rust resistance.
Technical Specifications
| Model | DX-40F |
| Wheel Material | Nylon |
| Mounting Height | 73 + 8mm (adjustable) |
| Wheel Diameter | 43mm |
| Wheel Width | 18mm |
| Top Plate Size | 55 × 55mm |
| Screw Hole Diameter | 6.5mm |
| Hole Spacing | 42 × 42mm |
| Mounting Type | Top Plate (4 holes) |
| Single Load Capacity | 50 kg (110 lbs) |
| Four-Unit Load Capacity | 100 kg (220 lbs) |
Key Features
One-piece formed shell — practical, durable, rust-resistant
360° rotation with integrated leveling adjustment
High-quality nylon wheel — wear-resistant, smooth rolling
No-drill mounting plate with precise hole positioning
Convenient to move and fix in one integrated design
Typical Applications
Communication equipment, semiconductor manufacturing, testing equipment, display manufacturing, ATM equipment, vending machines, aluminum profile frame equipment, light furniture, medical carts.
