Model: DCRC-65
|
Japanese Heavy Low Gravity Casters
DCRC-65 2.5" Japanese Rigid Caster with Top Plate
Nylon 65mm · Top Plate · 500kg Load · Fixed Direction
65mm (2.5")
Wheel Ø
500 kg (1,100 lbs)
Single Load
undefined+mm
Height
Top Plate (4 holes)
Mounting
Product Overview
DCRC-65 is a 2.5" Japanese-style heavy low gravity rigid caster — fixed direction without swivel. 500kg load capacity. Provides stable linear movement for heavy conveyor systems and fixed-direction equipment.
Technical Specifications
| Model | DCRC-65 |
| Wheel Material | Nylon |
| Wheel Diameter | 65mm (2.5") |
| Wheel Width | 48mm |
| Installation Height | 98mm |
| Top Plate Size | 100 × 100mm |
| Hole Spacing | 78 × 78mm |
| Mounting Type | Top Plate (4 holes) |
| Movement | Rigid (Fixed Direction) |
| Single Load Capacity | 500 kg (1,100 lbs) |
| Four-Unit Load Capacity | 2,000 kg (4,400 lbs) |
Key Features
Fixed direction for stable linear movement
Japanese low gravity heavy-duty design
500kg high load capacity
Top plate mounting for easy installation
Rigid design for guided movement
Typical Applications
Conveyor systems, fixed-direction heavy equipment, machinery requiring directional stability.
