Model: DCRC-75
|
Japanese Heavy Low Gravity Casters
DCRC-75 3" Japanese Rigid Caster with Top Plate
Nylon 75mm · Top Plate · 600kg Load · Fixed Direction
75mm (3")
Wheel Ø
600 kg (1,320 lbs)
Single Load
undefined+mm
Height
Top Plate (4 holes)
Mounting
Product Overview
DCRC-75 is a 3" Japanese-style rigid caster without swivel. The largest fixed-direction option with 600kg load capacity. Provides maximum stability for heavy linear movement applications.
Technical Specifications
| Model | DCRC-75 |
| Wheel Material | Nylon |
| Wheel Diameter | 75mm (3") |
| Wheel Width | 48mm |
| Installation Height | 108mm |
| Top Plate Size | 100 × 100mm |
| Hole Spacing | 78 × 78mm |
| Mounting Type | Top Plate (4 holes) |
| Movement | Rigid (Fixed Direction) |
| Single Load Capacity | 600 kg (1,320 lbs) |
| Four-Unit Load Capacity | 2,400 kg (5,280 lbs) |
Key Features
Fixed direction for stable linear movement
Largest Japanese-style rigid caster
600kg extreme load capacity
Top plate mounting for easy installation
Rigid design for guided movement
Typical Applications
Heavy conveyor systems, large fixed-direction equipment, machinery requiring maximum directional stability.
