Model: DCRS-65
|
Japanese Heavy Low Gravity Casters
DCRS-65 2.5" Japanese Swivel Caster with Top Plate
Nylon 65mm · Top Plate · 500kg Load
65mm (2.5")
Wheel Ø
500 kg (1,100 lbs)
Single Load
undefined+mm
Height
Top Plate (4 holes)
Mounting
Product Overview
DCRS-65 is a 2.5" Japanese-style heavy low gravity swivel caster without brake. 360° rotation with 500kg load capacity. The standard choice for Japanese-style mobile equipment.
Technical Specifications
| Model | DCRS-65 |
| Wheel Material | Nylon |
| Wheel Diameter | 65mm (2.5") |
| Wheel Width | 48mm |
| Installation Height | 98mm |
| Top Plate Size | 100 × 100mm |
| Hole Spacing | 78 × 78mm |
| Mounting Type | Top Plate (4 holes) |
| Swivel | 360° rotation |
| Single Load Capacity | 500 kg (1,100 lbs) |
| Four-Unit Load Capacity | 2,000 kg (4,400 lbs) |
Key Features
Japanese low gravity heavy-duty design
500kg high load capacity
360° smooth swivel rotation
No brake — economical choice
Standard 2.5" size
Typical Applications
Mobile carts, industrial equipment, machinery where brake is not required.
