Model: DCRS-75
|
Japanese Heavy Low Gravity Casters
DCRS-75 3" Japanese Swivel Caster with Top Plate
Nylon 75mm · Top Plate · 600kg Load
75mm (3")
Wheel Ø
600 kg (1,320 lbs)
Single Load
undefined+mm
Height
Top Plate (4 holes)
Mounting
Product Overview
DCRS-75 is a 3" Japanese-style swivel caster without brake. 75mm wheel for maximum load distribution, 600kg single-unit load capacity. The standard choice for heavy Japanese-style mobile equipment.
Technical Specifications
| Model | DCRS-75 |
| Wheel Material | Nylon |
| Wheel Diameter | 75mm (3") |
| Wheel Width | 48mm |
| Installation Height | 108mm |
| Top Plate Size | 100 × 100mm |
| Hole Spacing | 78 × 78mm |
| Mounting Type | Top Plate (4 holes) |
| Swivel | 360° rotation |
| Single Load Capacity | 600 kg (1,320 lbs) |
| Four-Unit Load Capacity | 2,400 kg (5,280 lbs) |
Key Features
Largest Japanese-style swivel — 3" wheel
600kg extreme load capacity
360° smooth swivel rotation
No brake for cost-effective mobile applications
Reinforced top plate for heavy-duty use
Typical Applications
Heavy mobile equipment, large industrial carts, machinery where brake is not required.
