Heavy Duty
🎁
Free Sample — Evaluate before you order. Contact us with your shipping details.
Model: DCST-60F
|
Leveling Casters
DCST-60F Heavy Duty Stainless Steel Leveling Caster
Stainless Steel 304 · 2.44" Wheel · 1,300 lb (590 kg) Load
2.44" (60mm)
Wheel Ø
590 kg (1,300 lbs)
Single Load
3.94"
Height
Drop-Forged Top Plate (4 holes)
Mounting
Product Overview
Heavy duty stainless steel leveling caster with 590kg single-unit capacity. The 2.44" (60mm) nylon/polyurethane wheel provides superior load distribution and stability. Drop-forged top plate ensures maximum strength for the most demanding industrial applications. Perfect for heavy equipment in corrosive or hygienic environments.
Technical Specifications
| Model | DCST-60F |
| Material | 304 Stainless Steel (Drop-Forged Top Plate) |
| Wheel Material | Reinforced Nylon / Polyurethane |
| Wheel Diameter | 2.44" (60mm) |
| Wheel Width | 1-3/16" (30mm) |
| Mounting Height | 3.94" (100mm) |
| Top Plate Size | 3-3/4" × 3-3/4" (95 × 95mm) |
| Bolt Hole Spacing | 2-5/8" × 2-5/8" to 3-1/8" × 3-1/8" (67×67 to 80×80mm) |
| Mounting Type | Drop-Forged Top Plate (4 holes) |
| Swivel | 360° rotation with precision bearing |
| Leveling | Integrated foot with 12mm adjustment |
| Single Load Capacity | 590 kg (1,300 lbs) |
| Four-Unit Load Capacity | 2,360 kg (5,200 lbs) |
| Operating Temperature | -40°C to +100°C |
| Certifications | RoHS Compliant, FDA wheel options |
Key Features
304 stainless steel drop-forged top plate — maximum strength
1,300 lb heavy-duty load capacity
60mm wheel for superior load distribution
Precision bearing for smooth 360° rotation
12mm leveling adjustment range
Wide temperature tolerance for industrial use
RoHS compliant, FDA wheel options for food service
Typical Applications
Heavy food processing equipment, pharmaceutical manufacturing, large medical devices, marine heavy equipment, chemical processing, clean room automation, industrial kitchens.
